VST Filter

Plastic

With 2 brass plugs and 2 extension tubes.
(2 inputs & 2 outputs).

NTPF Ports: 1/4"

Aluminium

With 2 brass plugs and 2 extension tubes.

1/4" NPTF Ports

(2 inputs & 2 outputs)

Replaces: 61N-24560-00 (Yamaha), 15410-94400 (Suzuki)

Engines:

15-60HP

DT5 / DT6 / DT8G-Y (1986-00)

DT9.9K / DT15K-G-Y (1986-00)

DT25C / DT30C-K-Y (1989-00)

DT20 / DT25 / DT30G-Y (1986-00)

DT55 / DT65J-X (1988-99)

DT40C-W-G-X (1986-99)

Max. capacity: 150 l/h.

Clear Bowl

Complete fuel filter with transparent bowl.

For outboards engines.

For outboards engines.

Max. capacity: 150 l/h

Replacement element for filter with transparent bowl NSP2545

Replaces: 68V-13915-00

Engines:

F115 (2000-09)

F200 TXR (2002-09)

LF200 TXR (2002-09)

F225 TXR (2002-09)

F225 TUR (2002-09)

Capacity: 50 l/h

Hose: 6-8 mm

Pack: 1 x blister

Transparent plastic in line filter for petrol and diesel.

GOLDENSHIP

Replaces: 6P3-24564-00

Engines:

F/LF 150 - F300(2006-14)

VZ150 - VZ300 (2006-14)

Z200 -Z300 (2006-14)



Hose: 6, 8, 10 mm

Pack: 1 x blister

In-line. Clear body permits visual inspection. Racors 6-8-10 mm.

GOLDENSHIP

Capacity: 150 l/h

Hose: 8-10 mm

Pack: 1 x blister

Transparent plastic in line filter for petrol and diesel.

GOLDENSHIP

Made in Machined Brass

GOLDENSHIP

Thread: 3/8" NPT

Hose: 5/16" = 7.9 mm

Pack: 2x skinpack

Replaces: 61A-24563-00

Engines:

V6, 3’1L, D-T

28 micron

Heigth: 4-7/16"

Max Flow: 340lph / 60gph

Element: NSP3444

Bracket: Alluminum

Clear bowl: Yes

Central threads: 1 - 14

Head port size: 1//4-18NPTF

Height: 238mm.

Width: 102 mm.

Depth: 102 mm.

Weight: 0.9 kg.

Pressure drop: 0.61 PSI / 0.04 bar

Max. pressure: 7 PSI / 0.5 bar

Element removal underbowl: 25.4 mm. / 1"

Operating temp.: -40ºC + 124ºC / -40ºF + 255ºF

Micron: 10

NPTF Ports: 1/4"

Flow: 50 GPH

Cast Aluminium Bracket. With 2 brass plugs & 1 extension tube.

Ø hose: 1/4"

Plastic
